Production

Specialists in sheet metal processing
LASER CUTTING

Max Sheet Size

3,000 x 1,500 mm

Material Thickness (normal)

Steel up to 8 mm (w/O2 up to 8mm / w/N2 up to 5mm)

Stainless steel up to 6 mm

Aluminium up to 6 mm

Copper up to 3 mm

Machinery

Prima Power LPe6f + LSR6 – combined servo-electric punching, 3 kW fiber laser cutting (with O2 or N2) and marking + tapping station TU6 + upforming stations (4 pcs) + high-performance portal type loading and stacking robot for automatic material loading and part sorting (LSR).

TURRET PUNCHING

Max Sheet Size

3,000 x 1,500 mm

Material Thickness ( Normal)

Steel up to 8 mm

Stainless steel up to 4 mm

Aluminium up to 3 mm

Copper up to 4 mm

Machinery

Prima/Finn-Power F6-21 – CNC hydraulic turret punch press (30 T);

Amada Aries 245  – CNC eccentric turret punch presses (20 T) with raw material loading and skeleton unloading devices with fast working cycle.

BENDING

Max Bending Line Length

4,000 mm

Max Press Power

200 tons

Material Thickness (normal)

Steel up to 8 mm

Stainless steel up to 6 mm

Aluminium up to 6 mm

Machinery – CNC hydraulic and servo-electric press brakes

Gasparini PSG 200 (200 T);    Prima Power eP-0520 (55 T);

Amada HFT 50-20 (50 T);    Amada SPH-30 (30 T)

ROBOTIC BENDING

Max Bending Line Length

2,500 mm

Max Press Power

80 tons

Machinery

2 CNC hydraulic and servo-electric press brakes with 2 Motoman robots. Max part weight to bend up to 8 kg.

WELDING

We provide professional welding services in different techniques



  • MMA
  • MIG / MAG
  • TIG
  • SPOT
  • LASER
MACHINING

Our comprehensive machining capacity gives us the ability to meet the wide range of customers’ needs

  • Turning
  • Milling
  • Threading
  • Drilling
  • Sawing
FINISHING

We are experienced in different types of surface treatments (in-house and outsourced)



  • Adding and altering finishing (incl. galvanizing, painting, powder coating, passivation etc)
  • Removing and reshaping finishing (incl. tumble finishing, grinding, polishing, peening, other  mechanical finishing processes)
ASSEMBLING

In addition to wide selection of high-quality production processes we offer different assembling services



  • Sub and final assembly
  • Nut inserting press with automatic feeder
  • Joining
Materials

Our usual line of processed materials include ferrous and non-ferrous metals and plastics.



  • All qualities of steel incl. hot and cold-rolled, galvanised, stainless, PVC-coated,  pre-painted, electro-galvanised
  • Aluminium
  • Copper
  • Plastics incl. fiberglass reinforced plastics
